| 参数Model | 步距角Step Angle (Deg.) | 相数No.of Phase | 端电压Voltage(V) | 电压Current(A) | 电容Resistance(Ω) | 电感Inductance(mH) | 步长Step Avail(mm) | 推拉力Push/Pull Torque(N) | 里程Journey(mm) | 引出来线Leads | 接电源图Wdg | 形状图片图Fig |
| 28BYZ-09 | 15 | 2 | 5 | 0.46 | 10.8 | 0.0417 | 40 | ≧87 | a | 1 | ||
| 28BYZ-A01 | 15 | 2 | 24 | 0.16 | 150 | 85 | 0.0417 | 65 | ≧12 | a | 2 | |
| 35BY16Z | 7.5 | 2 | 9 | 0.5(constant） | 7.7 | 8.1 | 0.0167 | 35 | ≧14 | UL1332 24# | a | 3 |
| 35YC25Z-A02 | 7.5 | 2 | 12 | 0.6(constant） | 11 | 8.2 | 0.0254 | 100 | ≧5.3 | UL1061 28# | a | 4 |
| 35BYZ-B01F | 7.5 | 4 | 5 | 0.46 | 11 | 0.0254 | 40 | ≧75 | UL1061 28# | c | 5 | |
| 57BYZ-B022 | 7.5 | 4 | 12 | 0.67 | 18 | 18.7 | 0.0254 | 90 | ≧130 | UL1007 26# | c | 6 |
新款上市机电设备要能以的客户必须要 设计。
The motor can be designed &manufactured with customized request.
