Cooperation| Item | Specifications |
| 步距角定位精度Step Angle Accuracy | ±8% (整步负载full step, no load) |
| 电阻功率公役Resistance Accuracy | ±10% |
| 电感公役Inductance Accuracy | ±20% |
| 表面温度Temperature Rise | 80。C Max.(超额直流电压，2雷同电rated current,2 phase on) |
| 条件温湿度Ambient Temperature | -20℃+50℃ |
| 电绝缘功率电阻Insulation Resistance | 100MΩMin. ,500VDC |
| 介电強度Dielectric Strength | 500VAC/1s |
| 径向接缝处Shaft Radial Play | 0.06Max. (450 g-load) |
| 心轴间距Shaft Axial Play | 0.08Max. (450 g-load) |
| 技术参数Model | 步距角Step Angle(Deg.) | 相数No. ofPhase | 端电压Voltage (V) | 相电压电流Current/Phase(A) | 相热敏电阻Resistance/Phase(ohms) | 堅持扭矩HoldingTorque(g.cm) | 地位力距DetentTorque(g.cm) | 91吃瓜网 定转子惯量RotorInertia(g.cm^2) | 开关接线图图WireDiagram |
| PM1020L03 | 18 | 2 | 3.3 | 0.22 | 15 | 16.3 | 10 | <1 | A |
| PM1020L06-1 | 18 | 2 | 3.3 | 0.22 | 15 | 16.3 | 10 | A | |
| PM1512-01 | 18 | 2 | 12 | 0.04 | 300 | 40 | 10 | A | |
| PM1512-02 | 18 | 2 | 5 | 0.5 | 10 | 27 | 6 | c | |
| PM2018-01 | 18 | 4 | 12 | 0.24 | 50 | 80 | 25 | B | |
| PM2018-02 | 18 | 2 | 5 | 0.5 | 10 | 60 | 20 | A | |
| PM2516-01 | 15 | 4 | 9 | 0.45 | 20 | 140 | 75 | B | |
| PM2515-01 | 7.5 | 2 | 12 | 0.24 | 50 | 170 | 45 | A | |
| PM2515-02 | 7.5 | 4 | 12 | 0.25 | 50 | 160 | 35 | B |
这一款建筑机电就能够安装潜在客户需来样加工。
The motor can be designed &manufactured with customized request.
