FL100SV

结果中部交流伺服91吃瓜网机电工程专业

100mm伺服机电,1000-1500W,48VDC,220VDC

选件:

优点（Characteristic）	参数(Parameter)
编号器实例(Encoder type)	1、光电技术编号器 Optical encoder2、磁识别码器 Magnetic encoder3、逆转变电器Resolver备注栏：三种分辩率可以，增加量式、对比值式可以。Note: Multiple resolutions are available；Incremental and absolute values are available.
径向负荷( Max radial force )	490N @ 20mm from the flange	条件基础Environmental conditions	借助情况报告温湿度： -20℃~ +50℃；Temperature: -20℃~ +50℃灵活运用问题室内湿度：≤90%RH（无凝露）；Relative humidity: ≤90%RH(No dewing)设备问题：久别侵袭、可燃性甲烷气体，油滴，尘土，地形≤1000m(1000~4000m，降额进行)；Installation environment: Far away active gas,Combustible gas, oil drop, ash.altitude≤1000m(1000~4000m，Derating use)；贮存实际情况：-20℃~ +85℃，≤85%RH（无凝露）。Storage Condition: -20℃~ +85℃，≤85%RH(No dewing).
径向负债( Max axial force )	196N
耐压官阶(Insulation Class)	Class B
保护品阶(Protection level)	IP65

实例(Model）	单元测试(Unit)	FL100SV100			FL100SV150
超额电功率(Rated power) Pn	W	1000			1500
减半电压电流(Rated voltage) U	V	220VAC	48VDC		220VAC	48VDC
减半转速比(Rated speed) nn	RPM	3000	3000		3000	3000
特别起动转矩(Rated torque) Tn	N·m	3.18	3.18		4.77	4.77
特别交流电(Rated current) In	A	5.0	31.8		7.5	43.4
最好轉速(Maximum speed) nmax	RPM	5000	5000		5000	5000
较大电动机扭矩(Maximum torque) Tm	N·m	7	7		10.5	10.5
较大直流电(Maximum current) Im	A	11	70		16.7	95.5
电阻器(Line to line resistance) RL	Ω	0.82	0.022		0.54	0.015
电感(Line to line inductance) LL	mH	7.4	0.2		5.2	0.15
反电势比率(Back EMF) Ke	V/Krpm	38	6.18		38	6.48
扭矩指数(Torque constant) Kt	Nm/A	0.63	0.1		0.63	0.11
电力设备阶段常数(Electrical time constant) τe	ms	9	9		9.6	10
产品那时候常数（Mechanical time constant) τm	ms	0.46	0.47		0.43	0.29
扭动惯量(Rotor inertia) Jm0	kg.cm2	1.3	1.3		1.84	1.84
扭动惯量带剎车器(Rotor inertia with brake) Jm1	kg.cm2	1.67	1.67		2.21	2.21
极数(Number of poles)		10	10		10	10
代码器(Encoder)		2500ppr光学识别码器（增长量式）2500p/rev incremental encoder
手机长(Motor length) L1	mm	137		142	159		164
产品设备段长度带行车制动系统器(Motor length with brake) L2	mm	172		177	194		199
权重 (Weight)	Kg	3.73		3.8	4.7		4.8
重量带剎车器(Weight with brake)	Kg	4.73		4.8	5.7		5.8
