机电设备轴径

Motor Shaft   diameter

适用轴径4mm,5mm,6mm,6.35mm

Suitable for shaft   diameter 4mm,5mm,6mm,6.35mm

内存水温 Storage Temperature

-40℃～85℃

保举钓鱼任务状况

Environmental   conditions

娱乐场所Application

无侵蚀作用性，容易燃烧，易爆，导电性气休，夜体和烟尘

No corrosive, flammable, explosive, conductive   gas, liquid and dust.

作业温湿度Temperature

-25℃～80℃

温度Humidity

不不低于85% RH

No more than 85% RH

用电电流电压 Supply Voltage

5V±0.5V

耗损感应电流 Current Consumption

≤120mA

差分旌旗灯号复制粘贴

Differential   Single Output

5V,GND,Z-,Z+,B-,B+,A-,A+,HW-,HW+,HV-,HV+,HU-,HU+

插入电平体例  Output Level mode

TTL电平 (TTL Compatible)

目录旌旗灯号参数

Index Width

1/4T or 1/2T or 1T

 (遵循要来样加工 According to the needing)

差分输人电压降

Differential   Output Voltage

高电平导入输出功率(VoH) ≥3.4V

High Level   Output (VoH) ≥3.4V

机电

性能

Electrical Parameter

低电平复制粘贴额定电压(VoL) ≤0.5V

Low Level Output   (VoL) ≤0.5V

差分旌旗灯号进入战略布局

Differential   Signal Output Format

线动力26C31

Line Drive 26C31

能选分辩率（象限Unit：线/CPR）

Optional   Resolution

2500线(假设按照需注意订制)

极对数计算 Pole-pairs

2/4/5对极(可私人订制 According)

HU/HV/HW旌旗灯号相位差

120°

占空比 Duty Cycle

50% ±10%

A/B旌旗灯号相位差 Phase difference

 90°±10°

 搭配频度

Frequency Response

≤500KHz        侧重：旌旗灯号频率和次数 = (转动速度(Rpm)×线数)/60

Note: The signal frequency = (Speed(Rpm) *  number of Lines)/60
